| Supply Ability : | 50 Unit/Units per Month Horizontal glass hot pressing machine |
| Price : | $5,000.00 - $15,000.00/Units |
Using the world's leading German Siemens PLC program control, superior performance and accurate operation.
The touch screen operation is simple and intuitive, and the picture is real.
Using Japanese Fuji servo motor feeding and bending, it can fold any shape of straight line, angle and round orphan combination
Four storage tanks can be placed in 4 kinds of aluminum strips, and the maximum number of continuous processing can reach 9999 pieces
It can set the size of aluminum frame of 32 kinds of specifications. The aluminum frame of the same size can be processed continuously, and the aluminum strip is automatically continued.
Automatically avoid aluminum strip joints during bending and cutting, and automatically cut after bending
Manually debug each action for easy equipment maintenance
Aluminum weight | 5.5-24mm |
Max size of producessed aluminum bar | 2000*2000mm |
Min size of producessed aluminum bar | 250*250mm |
Aluminum bar transfer speed | 120m/min |
Working speed | For 30 seconds(1000*1000mm) |
Power | 380V/50HZ |
Boundary dimension | 1050*2100*2200(Length*width*height) |
|
|
